New

Coal-Based Columnar Activated Carbon: The Powerhouse of Purification

Why Choose Coal-Based Columnar AC? Get Free Quote High Adsorption 900-1100 Iodine Value (mg/g) for superior contaminant removal Robust Structure Crush strength >98%, ideal for high-pressure systems Versatile Applications Water Treatment (removes heavy metals, organic pollutants) Air Purification (VOCs, odors, industrial fumes) Chemical Catalysis (acid gas recovery, solvent recovery) Key Advantages Cost-Efficient: Longer lifespan (3-5 years) vs. granular carbon Eco-Friendly: Regeneratable via thermal reactivation (up to 8 cycles!) Custom Sizes Diameter 1.5-4.0mm, tailored to your reactor design Coal-based granular activated carbon (GAC) is a material produced from coal that has undergone a process of activation, creating a high surface area with numerous pores. This material is widely used for various applications, including water treatment, air purification, and other industrial processes. Production and Properties: Raw Material: GAC is typically made from coal, but other carbon-rich materials like wood and coconut shells can also be used. Activation Process: The coal is heated to a high temperature (800-1000°C) under controlled conditions, often using steam or other oxidizing gases, to develop its porous structure. Porous Structure: The activation process creates a network of pores on the surface of the carbon granules, significantly increasing their surface area and adsorptive capacity. Applications: Water Treatment: GAC is...

Learn More +

Activated Carbon in Gold Smelting: The Silent Hero of Precious Metal Recovery

#GoldMining #Metallurgy #SustainableMining Get Free Quote Ever wondered how tiny gold particles are efficiently captured from ore? The answer lies in activated carbon—a powerhouse material revolutionizing gold smelting. Dive into the science, specs, and success stories behind this critical technology! Why Activated Carbon Reigns Supreme in Gold Recovery Adsorption Genius CIPCIL Processes: Activated carbon traps gold-cyanide complexes (Au(CN)₂⁻) with >95% efficiency. High Surface Area: 800–1200 m²/g (ideal for microporous gold adsorption). Selectivity: Prioritizes gold over base metals like Cu/Fe (critical for ore purity). Performance Metrics That Matter Gold Loading Capacity: 200–300 g Au/ton carbon (top-grade coconut shell AC). Hardness: ≥95% (minimizes attrition in aggressive leaching tanks). Particle Size: 1–3 mm (optimizes flow dynamics in adsorption columns). Industry-Proven Case Studies Ghana’s Ashanti Goldfields Challenge: Low-grade ore (1.2 g Au/ton) with high clay content. Solution: Coconut-shell AC with 1050 m²/g surface area + 98% hardness. Result: Recovery rate jumped from 82% to 93%, slashing cyanide use by 25%. Australian Heap Leaching Innovation Breakthrough: Reactor-grade AC pellets (4–6 mm) for coarse ore. Outcome: 40% faster adsorption cycle + 30% lower carbon loss. Sustainability Edge Regeneration: Thermal reactivation (600°C) allows 5–8 reuse cycles, cutting waste by 70%. Eco-Certified: RJC-compliant (Responsible Jewellery Council) coconut-shell carbon....

Learn More +

Activated carbon: the wonderful world of porous materials

As a highly adsorbent material, activated carbon continues to show unique value in environmental protection, energy development and other fields due to its developed pore structure and huge specific surface area (usually up to 500-1500 m²/g). Its preparation raw materials include renewable resources such as coconut shells, wood, and coal, and its green characteristics make it an important material for sustainable development. Get Free Quote 1. Core application areas Environmental governance Water treatment: can remove heavy metals (such as lead, mercury) and organic pollutants, and activated carbon filters are commonly used in municipal water supply systems Air purification: adsorbs indoor pollutants such as formaldehyde and VOCs, and the adoption rate of vehicle air filters is over 80% Medical health First aid detoxification: prevents the absorption of poisons through surface adsorption Blood purification: key filter medium in artificial kidney devices Industrial catalysis As a catalyst carrier, it is widely used in: \ce{2SO2 + O2 ->[activated carbon] 2SO3} and other chemical reactions, which is about 40% more efficient than traditional carriers 2. Frontier research directions Structural regulation Develop hierarchical pore structure materials to simultaneously improve microporous adsorption and mesoporous mass transfer efficiency The specific surface area of ​​graphene composite carbon materials exceeds...

Learn More +

Application technology of activated carbon in industrial waste gas treatment

Adsorption mechanism and technical parameters Working principle Get Free Quote Physical adsorption: Relying on a specific surface area of ​​500-1500㎡/g, it captures small molecular VOCs (such as benzene and formaldehyde) through micropores (<2nm) Chemical adsorption: Surface carboxyl and phenolic hydroxyl groups combine with polar pollutants (such as ethyl acetate) Catalytic oxidation: Modified carbon loaded with MnO₂ or CuO can convert ozone into OH radicals and decompose difficult-to-adsorb organic matter Industry application cases Case 1: VOCs treatment in automobile painting workshop Exhaust gas parameters: Air volume 50000m³/h, benzene concentration 200mg/m³, humidity RH70% System configuration: Honeycomb activated carbon module: pore density 100CPI, thickness 400mm×2 layers Steam desorption system: 0.3MPa saturated steam, desorption rate＞92% Operation effect: Emission concentration＜20mg/m³, annual solvent recovery 12 tons (value ￥360,000 yuan) Case Example 2: Treatment of isopropyl alcohol waste gas in an electronics factory Challenges: Intermittent emissions (concentration fluctuations of 50-800 mg/m³), containing siloxane impurities Solutions: Silane pretreatment tower (siloxane removal > 95%) Columnar activated carbon (iodine value 1100 mg/g) adsorption tank Nitrogen protection regeneration system (oxygen content < 5%) Results: Emission compliance rate 100%, activated carbon replacement cycle extended to 18 months Case 3: H₂S odor control in a chemical plant Working conditions: Containing H₂S 500ppm, temperature...

Learn More +

How to select high-quality coal-based activated carbon？

Characteristics of coal-based activated carbon Get Free Quote Coal-based activated carbon is made from coal through carbonization and activation. Its main characteristics include: 1. High specific surface area: It has a rich microporous structure and provides a large number of adsorption sites. Good mechanical strength: It is wear-resistant and not easy to break, suitable for various filtration and adsorption devices. Chemical stability: It remains stable in acid, alkali and high temperature environments and is not easily destroyed by chemical reactions.Methods for selecting high-quality coal-based activated carbon Specific surface area Specific surface area is an important indicator for measuring the adsorption capacity of activated carbon. Generally speaking, the larger the specific surface area, the stronger the adsorption capacity of activated carbon. The commonly used measurement method is the BET (Brunauer-Emmett-Teller) method. Pore size distribution The pore size distribution of coal-based activated carbon has an important influence on its adsorption performance. According to the application requirements, select activated carbon with appropriate pore size distribution. For example, activated carbon used for water treatment should have more mesopores and macropores to effectively remove large molecular organic matter; while activated carbon used for gas adsorption requires more micropores to improve the adsorption capacity of small...

Learn More +

How to scientifically select coconut shell activated carbon?

5 core indicators (Take water treatment/air purification as an example) Get Free Quote 1. Lock in key performance parameters Iodine adsorption value (Iodine Number) Significance: Measures the adsorption capacity of micropores (<2nm) and determines the efficiency of removing small molecular organic matter (such as pigments, residual chlorine). Selection criteria: Drinking water grade: ≥1000 mg/g Industrial wastewater: ≥800 mg/g Testing tips: Ask the supplier for ASTM D4607 or GB/T 12496.8 test report, focusing on laboratory temperature and humidity conditions. Carbon tetrachloride adsorption rate (CTC Adsorption) Significance: Reflects the capacity of mesopores (2-50nm) and determines the interception capacity of macromolecules such as VOCs and oils. Selection criteria: Air purification: ≥60% Gold purification: ≥75% Pore Size Distribution Ideal ratio (determined by BET method): Micropores (<2nm): 40%-50% Mesopores (2-50nm): 50%-60% Macropores (>50nm): <5% Application matching: Gas adsorption: priority given to those with a high proportion of mesopores Water treatment: balance of micropores and mesopores Abrasion Resistance Test method: RO-TAP vibrating screen simulates transportation loss (ASTM D3802) Qualified line: ≥95% (to prevent powdering and clogging of filter element during use) Ash content and pH value Food grade: ash content ≤3%, pH 6-8 Industrial grade: ash content ≤8%, pH can be relaxed to 5-9 II. Scenario-based...

Learn More +
